INSTALLATION CHECK LIST
System Data Flatpack2 PS System
Flatpack
Power Supply System, type:
rticle No.:
Site, name:
Serial No.: Software, version No.:
Rectifiers, type & number of:
C Input Voltage, measured: Battery Type: Battery Capacity:
Installation carried out by, name:
Site Preparations
CARRY OUT FOLLOWING: OK
1. Organize the installation site
o Check min. clearances for cabinet access: front access, 60cm, top access, 20cm
o Check that the levelled surface is able to support 600 kg (cabinetized systems)
o Ensure the installation site is suitably ventilated and in a non-explosive atmosphere. 60V systems in RAL areas
2. Prepare the installation tools
o Check that insulated tools suitable for telecom installations are used
3. Prepare AC Supply: AC input cable(s) and fuses
o Check the AC supply is the correct type, and that the external AC fuses and AC input cable(s) are suitably rated
Mechanical Installation Power is OFF!
CARRY OUT FOLLOWING: OK
4. Remove packaging and check equipment
o Check you have received all the parts, correct cabinet, documentation, batteries (if applicable), etc
o Inspect the equipment for physical damage (report any damages)
o Leave rectifier modules in their packaging or in the selves, if factory installed. (commissioning task)
5. Remove top cover and dummy front panels
o Check that cable entry from the top is possible
6. Position and fasten the cabinet or subassembly
o Cabinets on levelled surface, adjust the legs. If necessary, unscrew the legs and fasten the cabinet to floor
o Subassemblies in existing 19” or in ETSI cabinets, using brackets. Mount the support & heat deflecting plate
7. Mount the batteries on the shelves
o Start (if applicable) on the lower shelf first, and continue upwards
o Do not terminate the battery cables yet!
Electrical Installation Power is OFF!
CARRY OUT FOLLOWING: OK
8. Make the system completely voltage free
o Switch OFF or remove all load fuses (MCB1, MCBx), battery fuses (Fb1, Fbx) and external AC supply fuses
9. AC Connections
o Check AC configuration: The AC terminals are correct configured to the external AC supply
o Connect the AC Earth wire (PE) to the terminals AC Earth (PE)
o Connect the AC input cable(s) to the terminals. Cable and terminal block labeling are to correspond
10. DC Connections Load Circuits
o Terminate DC Earth (TE): Common DC Output Rail is connected to TE at only one place
o For each DC load, connect one of the cables to the common DC output rail, and the other directly to the MCB
11. DC Connections Alarm & Signal Circuits
o Refer to your system’s connection drawings and configuration, or to the Factory Settings in the Quick Start Guide
o Terminate Alarm Circuit cables to the relay output terminals
o Terminate Signal Circuit cables to the digital input/output terminals
12. DC Connections Battery Cables Careful! Use correct polarity.
For each battery shelf,
o Mount 3 intercell links to connect in series 4 battery blocks, (In 24V systems: 1 link and 2 blocks)
o Connect battery cables to fuses and common DC rail, and to the shelf’s outer terminals; (+) and (-)
o Connect battery symmetry cables, if applicable, to the input terminals
o Connect the temperature sensor cable, if applicable, to the input terminals, and fix the sensor (at the end of the
cable) to a suitable place in the middle of the installed battery bank
