4.3.1 LED Indications
Functions of front panel LED indicators
LED Colour Main function Auxiliary function
green Unit is ready for operation
Inverter
green
Voltage and frequency of source
Inverter within permissible limit
Flashing when inverter overload
is detected
Mains
green
Voltage and frequency of source
Mains within permissible limit
Flashing when “Load on mains” is
activated (see menu 2)
Load on Inv.
green
Load feeding by source Inverter
Load on Mains
green Load feeding by source Mains
Sync.
green
Inverters are synchronized to
mains phase and frequency
red
Collective Failure (the allocation
of the individual trouble codes is
programmable)
4.3.2 Adjustment keys
The adjustment takes place with four front keys:
Front keys
Function

 during menu item selection: change to
previous item (parameter)
 during adjustment mode: increase value

 during menu item selection: change to next item (parameter)
 during adjustment mode: decrease value
ENT
 enter menu (long pressed)
 enter submenu
 save parameter and leave submenu
ESC
 leave the menu without changing
 enter error list
