Static Transfer Switch
STS207
User Manual
Page 9 (28)
ELTEK VALERE DEUTSCHLAND ©2009 UM_STS207_WEB_E_R1.4
3.2 Optional equipment for STS assembly:
AC Rack ACR INV222-6.75 LV (assembly set 19” sub rack 2U for max. three inverters INV215-24,
INV222-48 or INV222-60 and for one static transfer switch STS207-24V or STS207LV including
a wired backplane): Material code= 502-222-315.LV
AC Rack ACR INV222-6.75 HV (assembly set 19” sub rack 2U for max. three inverters INV222-
110 or INV222-220 and for one static transfer switch STS207HV including a wired backplane):
Material code= 502-222-315.HV
Figure 2. AC Rack ACR INV222-6.75 fully equipped
with three inverters INV222 and
one static transfer switch STS207
