Static Transfer Switch
STS207
User Manual
Page 24 (28)
ELTEK VALERE DEUTSCHLAND ©2009 UM_STS207_WEB_E_R1.4
Communications interface CAN-Bus, proprietary protocol; redundant synchronization bus;
Ethernet 10/100MB Half/Full (WEB server, SNMP, SMTP, SNTP)
Ambient temperature operation: -20°C to +55°C; storage: -40°C to + 85°C
Cooling fan cooling (temperature regulated; monitored)
Max. installation altitude 1500m
Audible noise 45dBA
Type of construction 1/4 x19’’, 2U
Surfaces powder coating RAL 7035 (front panel only) with black imprint;
constructive parts: anodized metal
Dimensions (W/H/D) 106.4/88.4/335 mm
Minimum installation depth 400mm (in combination with an assembly set 19’’ sub rack)
Weight approx. 2.2 kg
Connectors Rear: AC inputs/output, DC input and signalization
(DIN 41612-M-connector);
Front: Ethernet (RJ45), CAN (RJ11)
Applicable standards:
Mechanical construction acc. to VDE 0160 edition 5.88 chapter 7.2.2
Protection class IP20
Climatic conditions acc. to IEC 721-3-3 class 3K3/3Z1/3B1/3C2/3S2/3M2
RFI suppression / immunity CE- label; ((EN50081-1; EN55011/55022 class “B”; EN50082-2;
EN61000-4 part 2/3/4/5)
Compliance to safety standards acc. to EN60950-1; VDO0100 T410; VDO0110; EN60146
