1. Outline of Appliance
1 High voltage output 1
2 High voltage output 2
3 Ground terminal
4 Connector, release signal (not with type KNH18/__D)
5 Socket, system input
6 Fuse (see nameplate)
7 Master switch ON/OFF
8 Rotary button for setpoint settings (not with type KNH18/__D)
9 Pilot lamp
Fig. 1:
KNH18
High Voltage
Generator
Z00093y
KNH18
1 2 3 4 5 6 7 8 9
