ELTRA ELEMENTRAC CS-d - Top Mounting Plate

Spare parts
105
11.1.7 Top mounting plate
DANGER
D8.0005
Risk to life caused by an electric shock
Exposed power contacts – high voltage
• An electric shock can cause serious injuries in the form of burns, cardiac
arrhythmia, respiratory failure or cardiac arrest.
• Set the mains switch on the analyzer to position 0 and unplug the
mains plug from the socket.
A
Fig. 60: Top mounting plate
1
2
3
4
5
6
7
1
8
9
10
