ELTRA ELEMENTRAC CS-d - Safety Symbols on the Machine

Safety
12
2.7 Safety symbols on the machine
Safety symbols on the ELEMENTRAC CS-d provide warnings about risks when using the
machine.
The following safety symbols can be found on the analyzer:
Fig. 1: Safety symbols on the analyzer
Position
Component
Description
1
The warning signs at the top on the back
and on the right-hand side warn that the
covers may only be opened by qualified
personnel.
2
3
The warning signs on the furnace opening
warn of a risk of burns and crushing on
fingers or hands.
4
5
The warning sign on the dust filter housing
warns of burns.
2
1
4
5
3
