ELTRA ELEMENTRAC CS-d - Closing the Dust Box

Maintenance
74
10.2.2.3 Closing the dust box
The following diagram shows the dust box at the back of the HTFr:
Fig. 31: Dust box on the back of the HTFr
Close the dust box as follows:
1. Place the cover (3) onto the housing of the dust box (1).
2. Evenly tighten the screws (2) and (4) to secure the cover.
The dust box is closed.
2
1
3
4
