While lifting the lower head bracket, remove
the tension release rod. Without disconnecting
and cables, lift and rotate the print head so that
the surface can be inspected.
Do not unplug the print head. The cable pro-
vides ground for E.S.D. protection.
Carefully clean the print head surface with 91%
Isopropyl alcohol and a soft cloth or cotton
tipped swab.
Do not use a sharp or metal instrument to
scrape the stuck label from the print head. The
surface can be easily damaged.
Print Head
CAUTION
CAUTION
Troubleshooting
980090-001 Rev. B 45
While lifting the lower head bracket, remove
the tension release rod. Without disconnecting
and cables, lift and rotate the print head so that
the surface can be inspected.
Do not unplug the print head. The cable pro-
vides ground for E.S.D. protection.
Carefully clean the print head surface with 91%
Isopropyl alcohol and a soft cloth or cotton
tipped swab.
Do not use a sharp or metal instrument to
scrape the stuck label from the print head. The
surface can be easily damaged.
Print Head
Troubleshooting
980090-001 Rev. B 45
