Step ➍
Remove
Mechanism
Labels can become stuck to several parts in side
the print mechanism. To clear labels stuck in-
side the mechanism, it must be removed from
the printer base.
Remove the three screws that secure the
mechanism to the base and the screw that
secures the ground wire. Carefully lift up the
mechanism and disconnect the four cables that
lead to the main board noting their positions.
Troubleshooting
980090-001 Rev. B 47
