13
4.5 Assembling Elvie Stride
Wash hands thoroughly before you begin. Once the parts have been
cleaned and sanitized, make sure they are dry and not moldy before putting
them together. Pay extra attention to the Diaphragm and ensure it is
completely dry.
1. Attach the Cover and Clip. Slide
the Hub into the Cover, ensuring
the hole for the Hub Connector is
aligned with the hole on the Cover.
Push the short end of the Clip
through the slot, and pull through
2. Push the Hub Connector
firmly into the Hub, ensuring
that it is fully inserted
3. Push the Valve and Diaphragm
onto the Breast Shield
