CCTV
Step 5: Select Authority tab and then assign the operation rights for particular user. Refer to fig 4-31.
Fig 4-31 Add User-Authority
If you want to delete the user, please select the user you want to delete in the user list box and then click “Delete” button.
If you want to modify the user, please select the user you want to modify in the user list box and then click “Setup” button to
modify its general information and authority.
If you want to change password of a user, please select the user in the user list box and then click “Change Password” button.
4.8 P.T.Z Configuration
P.T.Z configuration includes two submenus: serial port and advanced settings.
Serial port settings are as follows:
Step 1: Enter into MenuÆSetup Æ P.T.Z ÆSerial port tab. Refer to Fig 4-32:
Step 2: Select “enable” and setup the value of address, baud rate and protocol according to the settings of the speed dome.
Step 3: Configure all channels with the same parameters by selecting the “All” box and then doing the relevant setup.
Fig 4-32 P.T.Z Configuration-Serial Port
Definitions and descriptions of network stream:
Advance settings are as follows:
Step 1: Enter into MenuÆSetupÆ P.T.Z ÆAdvanced tab. Refer to Fig 4-33:
Step 2: In the Advanced tab, click preset “Setting” button to see a dialog box as Fig 4-34:
Fig 4-33 P.T.Z Configuration-Advanced Fig 4-34 Advanced-Preset
Parameter Meaning
Address The address of the PTZ device
Baud rate Baud rate of the PTZ device. Range form: 110, 300, 600, 1200, 2400,
4800, 9600, 19200, 34800, 57600, 115200, 230400, 460800, 921600.
Protocol Communication protocol of the PTZ device. Range from: NULL, PELCOP,
PELCOD, LILIN, MINKING, NEON, STAR, VIDO, DSCP, VISCA,
SAMSUNG, RM110, HY, N-control.
Simulative
Cruise
If enabled, no matter whether the PTZ device supports cruise or not, the
presets will cruise.
