Em-Trak A200 - Menu Navigation

Operation
Page 43
4.5 Menu navigation
Figure 19 Home page menu screen
4.5.1 Main / Sub menus
Menus are displayed as a set of icons which can be navigated by using the
controls. Selection of an icon will then display the information beneath in
accordance with Figure 20. Pressing the ‘Back / Home’ key will exit the menu.
HOME
16:58:29
SOG 21.1kt
UTC + 1h
COG 88.0°
50° 32.0286’ N
0° 55.2715’ W
Target list
Voyage
data settings
Target plot
Messages Alarms Own dynamic data System settings
INT. GNSS
!
