Em-Trak A200 - Information Displayed

Operation
Page 45
4.5.2 Data entry screens
Some screens allow you to enter data, such as vessel parameters. On these
screens you navigate to the desired field and select the appropriate menu
item. Some data entry items require a password, this is shown by means of a
‘Padlock’ icon. Pressing the ‘Back / Home’ key will exit these menus.
4.5.3 Keyboard / Keypad screens
Some screens require text or numeric entry. When these are selected, a virtual
keyboard is displayed which can be used to enter text or numbers.
4.5.4 Options menu
On certain screens, the Options Menu will bring up a further list of functions
specific to that screen. This is indicated by this icon.
4.6 Information displayed
Figure 21 Display layout
1WHOME Int. GNSS
16:58:29
SOG 21.1kt
UTC + 1h
COG 88.0°
50° 32.0286’ N
0° 55.2715’ W
Speed / Course
Time
Time oset
Menu title
Main display
area
Status indicators
Messages
RX
TX
Filtering
Blue sign (Inland only)
Navigation status
Alarms
Position
