7.3 Connecting external equipment
● Figure 34. shows an example of how external equipment could be
connected through the junction box accessory.
Figure 34 Connecting external equipment
When connecting external equipment the following procedures should be
observed.
● The common line should be connected to the sensor port if one is
available.
Displays
(ECDIS, Radar)
Junction Box
Ships sensor data (DGPS, GYRO, Heading)
18 Way data cable
14 Way Data cable
AIS Transceiver
To Next Page
