Installation
Page 14
3 Installation
3.1 Summary
Before beginning installation of your transceiver, please ensure you have any
necessary additional items as detailed below. It is strongly recommended that
you read all of the instructions in this manual prior to installation. If after
reading this manual you are unsure about any element of the installation
process please contact your dealer or support@em-trak.com for advice.
Figure 4 Typical installation configuration
Power in
Switch
NMEA 2000
Chartplotter
VHF antenna
VHF radio
USB
NMEA 0183 device
GPS antenna
(Optional)
AIS Class B
transceiver
(Only applicable to B923, B924, B953 and B954)
