Installation
Page 23
The B900 Series uses a simple bracket system to make installation as easy
as possible. Use the supplied bracket template to locate the desired position
of the transceiver and simply screw or stick (adhesive pads are also supplied)
the bracket to your vessel and then click the transceiver into the bracket. The
secure clip will hold the transceiver securely in even the most severe weather
and wave-shocks. For added security, there is a simple locking screw which
you can use to lock the transceiver to the bracket.
Figure 11 AIS transceiver mounting
