Emakefun RF-NANO User Manual

Copy right © 2018 Shenzhen Emakefun Technology co., Ltd.
18
00
CONFIG
Set NRF24L01+ module
01
EN_AA
Set up the receiving channel and automatic reply
02
EN_RXADDR
Enable receive channel address
03
SETUP_AW
Set address width
04
SETUP_RETR
Set the time and frequency of automatic retransm
ission of data
07
STATUS
Status register, used to determine the working s
tatus
0A~0F
RX_ADDR_P0~P5
Set the receive channel address
10
TX_ADDR
Set the receive channel address
11~16
RX_PW_P0~P5
Sets the valid data width of the receive channel
2.3 RF-NANO work module
NRF24L01+ there is a state machine inside the chip, which controls the conversion
between different working modes of the chip. NRF24L01+ can be configured as Shutdown、
Standby、 Idle-TX、 TX and RX Five working modes.The state transition diagram is shown
in figure 2-3-1.

Emakefun RF-NANO Specifications

General

Brand	Emakefun
Model	RF-NANO
Category	Control Unit
Language	English
