Emakefun RF-NANO User Manual

Copy right © 2018 Shenzhen Emakefun Technology co., Ltd.
19
Figure 2-3-1
Chapter3 realizes the communication between rf-nano
3.1 Implement two rf-nano point-to-point communication
3.1.1 connect method
Prepare two rf-nano or an rf-nano and NRF24L01+ module, and an Arduino UNO R3(Arduino NANO
V3.0), as shown in figure 3-1-1.
Transmitting device
（RF-NANO）
Receiving device
（RF-NANO）
2.4G
