IMPORTANT SAFETY INSTRUCTIONS P6
1450RPM 50Hz
1200900600300
U.S.g.p.m
H(m)
22
20
18
16
14
12
10
8
6
4
2
0
0 30 60 90 120 150
180 210 240 270 300
450037503000225015007500
55
60
65
70
75
80
85
85
80
H(ft)
10
20
30
40
50
60
70
Q(m³/h)
Q(LPM)
The user guide you are holding includes essential information on the safety measures to be
implemented for installation and start-up. Therefore, the installer as well as the user must
read the instructions before beginning installation and start-up. Keep this manual for future
reference.
The pump should be installed according to your local electrical installation ordinances and
regulations. Only qualified, licensed personnel should install the pump and the wiring.
This appliance cannot be used by persons (including children) with reduced physical, sensory or mental
capabilities or lack of experience and knowledge unless they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards involved. Children must not play with
the appliance.
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory
or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with
the appliance. Cleaning and user maintenance shall not be made by children without supervision.
3. IMPORTANT SAFETY INSTRUCTIONS
4. TRANSPORT AND STORAGE
The pump is fastened securely a wooden box for shipment. It should be stored in a dry area.
The center of the pump locate at the middle of the pump. It is recommended to place the lifting strap under
between Motor to Body and Body to pre - filter body to lift the pump in the following way:
The Eye bolt is only to use for motor lifting.
