5. COMPRESSOR NOMENCLATURE
Information printed on compressor label: model, voltage and frequency supply, bill of material.
5.1 COMPRESSOR MODEL CODE
COMPRESSOR SCROLL
TYPE
PACKAGING EXECUTION
ACCESSORIES EXECUTION
VOLTAGE & FREQUENCY SUPPLY
COMPRESSOR SIZE
EXTERNAL EXECUTION
ELECTRICAL EXECUTION
MODEL CODE
30
1
A C 01 01
A
A
COMPRESSOR FAMILY
SE = Scroll Embraco
VOLTAGE & FREQUENCY SUPPLY
C - 220V 50Hz 1~
O - 380-420V 50Hz/460V 60Hz 3~
NOMINAL CAPACITY
In Btu/h at 60 Hz x 1000
ARI conditions
E.g. 015=15000 Btu/h
APPLICATION CODE
2 = LBP
6 = MBP
REFRIGERANT
R404A, R452A, R449A, R448A, R134a, R513A
SE
2
015 GK C
5.2 COMPRESSOR BILL OF MATERIAL CODE
5.2.1 COMPRESSOR SIZE
1 – MBP models for 2-6hp
2 – MBP models for 7-13hp
3 – LBP models for 2-6hp
4 – LBP models for 7-13hp
