Embraco Scroll SE6015GS-O - Voltage and Frequency Supply; External Execution; Electrical Execution

13
5.2.3 EXTERNAL EXECUTION
Table 5.2.4
5.2.4 ELECTRICAL EXECUTION
5.2.2 VOLTAGE AND FREQUENCY SUPPLY
Table 5.2.2
VOLTAGE CODE RATED VOLTAGE & FREQUENCY
C 220V 50HZ 1~
O 380420V 50HZ / 460V 60HZ 3~
Table 5.2.3
EXTERNAL
EXECUTION
COMPRESSOR
SIZE
APPLICATION CONFIGURATION TYPE
01
2-6 hp MBP
Brazing connection; discharge tube ID Ø12.92mm ±5; suction tube ID Ø22.4mm ±5;
oil sight glass.
02
2-6 hp LBP
Brazing connection; discharge tube ID Ø12.92mm ±5; suction tube ID Ø22.4mm ±5;
Liquid Injection with DTC valve; oil sight glass.
03
7-13 hp LBP
Brazing connection; discharge tube ID Ø22.47mm; suction tube ID Ø28.83mm; Liquid
Injection with DTC valve; oil sight glass.
04
7-13 hp MBP
Brazing connection; discharge tube ID Ø22.47mm; suction tube ID Ø28.83mm; oil sight
glass.
11
2-6 hp MBP
Rotolock connection; threaded discharge connection 3/4“-16 UNF 2A, ID Ø9mm; threaded
suction connection 1 1/4“-12 UNF 2A, ID Ø19.2mm; oil sight glass.
12
2-6 hp LBP
Rotolock connection; threaded discharge connection 3/4“-16 UNF 2A, ID Ø9mm;
threaded suction connection 1 1/4“-12 UNF 2A, ID Ø19.2mm; Liquid injection with DTC
valve; oil sight glass.
13
7-13 hp LBP
Rotolock connection; threaded discharge connection 1 1/4“-12 UNF 2A, ID Ø19.2mm;
threaded suction connection 1 3/4“-12 UNF 2A, ID Ø26.4mm. Liquid Injection with DTC
valve; oil sight glass.
14
7-13 hp MBP
Rotolock connection; threaded discharge connection 1 1/4“-12 UNF 2A. ID Ø19.2mm;
threaded suction connection 1 3/4“-12 UNF 2A, ID Ø26.4mm; oil sight glass.
EXECUTION MOTOR TYPE CONFIGURATION TYPE
01
3 PHASE
Internal overload protector, terminal cover with gasket and wiring diagram, grounding screw.
04
1 PHASE CSR
CSR box with start and run capacitor, Internal overload protector, terminal cover with gasket and wiring diagram,
grounding screw.
