Embraco Scroll SE6015GS-O - Motor Protection

42
Table 10.4.1
10.4 MOTOR PROTECTION
Compressors are protected against overheating by the conventional inherent internal line break motor
protection, mounted on the motor windings.
The OLP (Overload protector) detects unusual motor temperature rise and/or abnormal high current
input. The OLP trip is influenced by several factors - working conditions, suction gas density/
temperature, supply voltage, etc.
10.5 DEGREE OF PROTECTION
The degree of protection provided by the terminal cover and CSR box supplied with the compressor is IP21, where:
2 – protected against solid objects over 12.5 mm (fingers or similar)
1 – protected against vertically falling drops of water or condensation
10.4.1 OVERLOAD PROTECTOR PARAMETERS
MODEL PHASE
DISC TEMPERATURE °C
TIME CHECK
(A)
RESET TIME
(SEC)
OPEN (±5 °C) CLOSE (±9 °C)
SE6015GK-SE6021GK
Single phase 105 61 65 2~10
SE2006GK-SE2010GK
SE6026GK-SE6030GK
Single phase 115 61 78 2~10
SE2012GK-SE2014GK
SE6015GS
Three phase 115 60 25 3~10
SE2006GS-SE2008GS
SE6018GS-SE6021GS
Three phase 120 60 32 3~10
SE2010GS
SE6026GS-SE6030GS
Three phase 120 60 42 3~10
SE2012GS-SE2014GS
SE6036GS
Three phase 145 60 41 3~10
SE2017GS
SE6043GS
Three phase 140 60 52 3~10
SE2020GS
SE6053GS-SE6067GS Three phase 140 70 78 3~10
SE6078GS-SE6089GS Three phase 120 60 ± 10 90 3~10
SE2023GS-O Three phase 140 60 52 3~10
SE2028GS-O Three phase 140 70 78 3~10
SE2031GS-O Three phase 140 70 78 3~10
SE2039GS-O Three phase 120 60 ± 10 90 3~10
