10.2.1 ELECTRICAL COMPONENTS SPECIFICATION OF SINGLE PHASE
10.2 ELECTRICAL COMPONENTS TYPES
The electrical components specified for each Embraco compressor model
are indicated in the Technical Datasheet or Embraco Product Selector on
www.embraco.com
The type of electrical components for each type of electric motor is indicated in Table 10.2. and is supplied as
compressor equipment.
Use of other electrical components than the ones approved by Embraco (listed in the
Technical Datasheets and in Embraco Product Selector on www.embraco.com for
each specific model) or their exclusion may damage the compressor and other parts
and cause serious injury to persons.
CSR boxes are delivered without connection cables as their length depends on installation where will be
assembled. Recommended wire section for connection cables is 11 AWG as indicated in below Table 10.2.
CAUTION
WARNING
Table 10.2 Electrical components types
MOTOR TYPE
PROTECTOR STARTING DEVICE CAPACITORS CSR BOX
INTERNAL VOLTAGE RELAY START RUN
RECOMMENDED
WIRE SECTION
SINGLE PHASE
CSR
✓ ✓ ✓ ✓
11AWG
3 PHASE
✓ X X X X
APPLICATION EMBRACO MODEL START CAPACITOR RUN CAPACITOR STARTING DEVICE
MBP
SE6015GK-C 160µF 330V 60µF 450V HLR3800-3E3D
SE6018GK-C 160µF 330V 60µF 450V HLR3800-3E3D
SE6021GK-C 160µF 330V 60µF 450V HLR3800-3E3D
SE6026GK-C 250µF 330V 80µF 450V HLR3800-3H3D
SE6030GK-C 250µF 330V 80µF 450V HLR3800-3H3D
LBP
SE2006GK-C 160µF 330V 60µF 450V HLR3800-3E3D
SE2008GK-C 160µF 330V 60µF 450V HLR3800-3E3D
SE2010GK-C 160µF 330V 60µF 450V HLR3800-3E3D
SE2012GK-C 250µF 330V 80µF 450V HLR3800-3H3D
SE2014GK-C 250µF 330V 80µF 450V HLR3800-3H3D
