EMC Connectrix B Series DS-5300B Hardware Reference Manual
Introducing the Connectrix DS-5300B
Port side of the DS-5300B
Figure 1 shows the port side of the DS-5300B
Figure 1 Port Side of the DS-5300B
1
2
7345 8 9 10
13 14 15 16
11 12
6
1 DS-5300B 9 FC Ports 16-23
2 Switch pull-out Tabt 10 FC Ports 24-31
3 System Status LED (top) 11 FC Ports 32-38
4 System Status LED (bottom 12 FC Ports 40-47
5 Ethernet Port 13 FC Ports 48-55
6 USB Port 14 FC Ports 56-63
7 FC Ports 0-7 15 FC Ports 64-71
8 FC Ports 8-15 16 FC Ports 72-79

EMC Connectrix DS-5300B Specifications

General

Brand	EMC
Model	Connectrix DS-5300B
Category	Switch
Language	English
