54
EMC Connectrix B Series DS-5300B Hardware Reference Manual
Specifications
Power supply specifications
The power supplies are universal and capable of functioning
worldwide without voltage jumpers or switches. They meet IEC
61000-4-5 surge voltage requirements and are autoranging in terms of
accommodating input voltages and line frequencies. Each power
supply has a built-in fan for cooling, pushing air towards the port
side of the switch.
Table 5 lists the power supply specifications for the DS-5300B.
Table 5 Power supply specifications
Specification Value
Inlet C13
Input voltage 90-264 VAC, 47-63HZ
BTU rating 1313 BTU/hr
Inrush current Maximum of 15A for period of 10-150mS
Input line protection Both AC lines are fused
Maximum output of one power supply 300 Watts
Nominal system DC power consumption 260 Watts
