Tasks to replace an I/O module
EMC VNXe3100/VNXe3150 — Replacing an Input/Output Module 5
Task 4: Remove the faulted I/O module
1. Lift the blue latch carefully until it ejects the I/O module from the connector.
2. Lift the module out and away from the canister and place it on a static free surface.
2
1
CL4688
