Emec KMS MF - B APPENDIX. CONSTRUCTION MATERIALS AND TECHNICAL INFO; Technical Specifications and Materials

53
B APPENDIX. CONSTRUCTION MATERIALS AND TECHNICAL INFO
TECHNICAL FEATURES
Power supply: 230 VAC (190–265 VAC) – 50/60 Hz
Power supply: 115 VAC (90–135 VAC) – 50/60 Hz
Power supply: 24 VAC (20–32 VAC) – 50/60 Hz
Power supply: 12 VDC (10–16 VDC)
Pump Strokes: 0–180 (0–140 for KMS AC MF)
Suction Height: 1,5 metres
Environment Temperature: 0–45°C (32–113°F)
Chemical Temperature: 0–50°C (32–122°F)
Installation Class: II
Altitude max 2000 m
Audible Noise: 73.4 dbA
Packaging and Transporting Temperature: -10–50°C (14–122°F)
Protection degree: IP 65
MANUFACTURING MATERIALS
Case: PP
Pump head: PVDF, Acrilic, SS *
Diaphragm: PTFE
Balls: CERAMIC, PTFE, SS *
Suction Pipe PVC
Delivery Pipe: PVDF
Valve Body: PVDF, PE, SS *
O-ring: FP, EP, PTFE *
Injection connector PVDF (ceramic, HASTELLOY C276 spring)
Level Probe: PVDF
Level probe cable: PE
Foot Filter: PVDF
*as ordered.
TECHNICAL INFORMATION
KMS
CAPACITY
cc / stroke
Max pressure
imp/min
Hoses
Pump
head
min cc/h
max
l/h
Min
GPH
Max
GPH
min max
bar PSI
1802 0,06 2 0,000016 0,53 0,06 0,19 18 261
180
4 x 6 L
1504 0,11 4 0,000029 1,06 0,11 0,37 15 217
180
4 x 6 L
1005 0,14 5 0,000037 1,32 0,14 0,46 10 145
180
4 x 6 L
0808 0,22 8 0,000058 2,11 0,22 0,74 8 116
180
4 x 6 L
0510 0,28 10 0,000074 2,64 0,28 0,93 5 72
180
4 x 6 L
0501 0,03 1 0,000008 0,26 0,03 0,09 5 72
120 4 x 6
I
0218 0,50 18 0,00013 4,76 0,50 1,67 2 29
180
6 x 8 M
TECHNICAL INFORMATION
KMSA
CAPACITY
cc / stroke
Max pressure
imp/min
Hoses
Pump
head
min cc/h
max
l/h
Min
GPH
Max
GPH
min max
bar PSI
1801 0,03 1 0,000008 0,26 0,03 0,09 18 261
180
4 x 6 LA
1503 0,08 3 0,000021 0,79 0,08 0,28 15 217
180
4 x 6 LA
103.5 0,10 3,5 0,000026 0,92 0,10 0,32 10 145
180
4 x 6 LA
085.5 0,15 5,5 0,000040 1,45 0,15 0,51 8 116
180
4 x 6 LA
057.5 0,21 7,5 0,000055 1,98 0,21 0,69 5 72
180
4 x 6 LA
0213 0,37 13 0,000098 3,43 0,37 1,20 2 29
180
6 x 8 MA
