18
8. BASIC SETTINGS
LCD backlit display
Storke Lenght Knob
Scroll and increase digit
Turn the pump on or off and exit from setup menu (without saving parameters)
Enter / exit from setup menu (saving parameters)
The “KMS MF” pump is equipped with a keyboard.To avoid any misunderstanding during next chapters all keys will be described
as shown on this legend:
“UP” key “ESC” key
“RIGHT” key “E” key
Menu navigation:
To enter into programming mode press and keep pressed “E” key from main screen (fig.3):
Main screen (fig.3) may appear different if “PPM” or “BATCH” mode is enabled. After about 4 seconds the pump will show
the password screen (fig.5):
Default password is “0000”. Just press “E” key. Otherwise insert password using “UP” and “RIGHT” keys.
E
ESC
fig.3
password
0000
fig.5
ON/OFF
STROKES
100 SPM
batch
waiting
upkeep
000m 00s
