Emerson Bettis G2 Series User Manual

July 2020
Installation, Operation and Maintenance Manual
VA-DC-000-1803 Rev. 2
40
Section 6: Actuator Support Information
Actuator Support Information
Item
No.
G01
WT.
G2
WT.
G3
WT.
G4
WT.
G5
WT.
G7
WT.
G8
WT.
G10
WT.
Module
Description
7
lb N/A 31 N/A N/A N/A N/A N/A N/A
2.5” Dia. H
Power Module
kg N/A 14.1 N/A N/A N/A N/A N/A N/A
7
lb N/A N/A 48 N/A N/A N/A N/A N/A
3.0” Dia. H
Power Module
kg N/A N/A 21.7 N/A N/A N/A N/A N/A
7
lb N/A N/A N/A 84 N/A N/A N/A N/A
4.0” Dia. H
Power Module
kg N/A N/A N/A 38 N/A N/A N/A N/A
7
lb N/A N/A N/A N/A 173 N/A N/A N/A
5.0” Dia. H
Power Module
kg N/A N/A N/A N/A 78 N/A N/A N/A
7
lb N/A N/A N/A N/A N/A 303 N/A N/A
6.0” Dia. H
Power Module
kg N/A N/A N/A N/A N/A 137 N/A N/A
7
lb N/A N/A N/A N/A N/A N/A 485 N/A
7.0” Dia. H
Power Module
kg N/A N/A N/A N/A N/A N/A 220 N/A
7
lb N/A N/A N/A N/A N/A N/A N/A 808
9.0” Dia. H
Power Module
kg N/A N/A N/A N/A N/A N/A N/A 367
7
lb 25.4 25.4 27.9 27.9 33.9 33.9 33.9 40.4
M18 Pump /
Reservoir, empty
kg 11.5 11.5 12.6 12.6 15.4 15.4 15.4 18.3
