Installation, Operation and Maintenance Manual
VA-DC-000-1803 Rev. 2
July 2020
43
Section 6: Actuator Support Information
Actuator Support Information
Item No. Wrench Size Item Qty.
Location or
Description
Recommended
Tool Style
1 - 110 3/4” 8 Hex Cap Screws Socket
1 - 120 3/4” 4 Hex Cap Screws Socket
1 - 160 9/16” 8 Hex Cap Screws Socket
1 - 180 1” 2 Stop Screws Open End or Adjustable
3 - 20 3/4” sq. 2 Tie Bar (female square) Open End or Adjustable
3 - 40 3/4” sq. 1 Piston Rod Male Drive
3 - 90 2 - 3/8” 2 Standard Hex Nuts Socket
3 - 100 15/16” 8 Hex Cap Screws Socket
3 - 120 1 - 1/8” sq. 1 Pipe Plug Open End or Adjustable
3 - 130 3/16” 2 Socket Cap Screws Allen
7 - 40 3/4” sq. 1 Piston Rod Male Drive
7 - 90 1 - 1/2” 6 Hex Nuts Socket
7 - 100 15/16” 8 Hex Cap Screws Socket
7 - 105 15/16” 8 Standard Hex Nuts Socket
7 - 115 15/16” 8 Hex Cap Screws Socket
7 - 120 15/16” 1 NPT Pipe Plug Open End or Adjustable
13 3/4” 2 Vent Check Assembly Open End
6.6 G5 Tool Style and Wrench Size
Table 11. G5 Tool Style and Wrench Size
6.7 G7 Tool Style and Wrench Size
Table 12. G7 Tool Style and Wrench Size
Item No. Wrench Size Item Qty.
Location or
Description
Recommended
Tool Style
1 - 110 3/4” 8 Hex Cap Screws Socket
1 - 120 3/4” 4 Hex Cap Screws Socket
1 - 160 9/16” 6 Hex Cap Screws Socket
1 - 180 7/8” sq. 2 Stop Screws Open End or Adjustable
1 - 190 2 - 3/8” 2 Heavy Hex Jam Nuts Open End or Adjustable
3 - 20 1/2” sq. 2 Tie Bar (ats) Open End or Adjustable
3 - 40 1/2” sq. 1 Piston Rod Male Drive
3 - 90 2” 2 Standard Hex Nuts Socket
3 - 100 3/4” 8 Hex Cap Screws Socket
3 - 120 1 - 1/8” sq. 1 Pipe Plug Open End or Adjustable
3 - 130 3/16” 2 Socket Cap Screws Allen
7 - 40 1/2” sq. 1 Piston Rod Male Drive
7 - 90 15/16” 6 Hex Nuts Socket
7 - 100 3/4” 4 Hex Cap Screws Socket
7 - 105 3/4” 4 Standard Hex Nuts Socket
7 - 115 3/4” 4 Hex Cap Screws Socket
7 - 120 5/8” sq. 1 NPT Pipe Plug Open End or Adjustable
13 3/4” 2 Vent Check Assembly Open End
