Figure 2. CMF400 sensor with remote booster amplifier and
core processor
Core
processor
housing
Process
fitting
Intrinsically
safe wiring
Explosion-proof
wiring
Sensor
housing
Approval tag
Approval
tag
Factory-
supplied
wiring
Calibration
tag
Customer
tag (if
requested)
Remote
booster
amplifier
