Figure 4. CMF400 sensor with remote booster amplifier and
junction box
STEP 1. Determining a location
Choose a location for the sensor based on the requirements described in
this section.
Approval
tag
Process
fitting
Explosion-proof
wiring
Junction
box
Approval
tag
Sensor
housing
Intrinsically safe
wiring
Remote
booster
amplifier
Factory-
supplied
wiring
Customer
tag (if
requested)
Calibration
tag
