43
Diagnostics and Troubleshooting
Note
You cannot change the values of the parameters while they are being displayed in the
Watch Window. The parameter in the setup screens will look like they have been changed
when they actually have not. To update a parameter, delete it from the Watch Window
selection.
Note
It is normal to have the Watch Window show up with the three motor parameters already
selected if the motor parameters window has been accessed previously. If you do not need
to view them, simply push the Clear All button and select the parameters you wish to
view.
Figure 37: Watch Window
The Watch Window is accessed by selecting Watch Drive Parameters from the Tools menu
or by clicking on the Watch Window icon on the toolbar.
The Watch Window will automatically appear as soon as you select a parameter from the
Select Drive Parameters dialog box. After you have selected the parameters you wish to
watch, click the Close button. The Select Drive Parameters dialog box will close and the
Watch Window will remain open.
Figure 38: Select Drive Parameters Dialog Box
