Specifications
Motor Wiring Color Cable
*Encoder Shield and Power Shield must be separated from each other all the way back to the
amplifier. They can be connected to the same enclosure walls via individual shielded
grommets (i.e., CGS-xxx).
**Protected Earth Ground can be connected at the motor and the amplifier only with no
connections to anything else in between, including frame ground.
***For proper thermal switch operation in a LONS motor, jumper THERM Ground (Green/
Red) to OV Common (Blue/Red).
Motor Encoder
Cable
Motor Encoder
Connector Pin #
(CONS/TONS)
Signal Name
Motor Cable
Colors
(Current)
Motor Cable
Colors
(Previous)
CFCO Cable
Colors
(8 Pair Shielded
Cable)
B A Blue Blue Blue
C A/ Orange Blue/White Orange
N B Green Green Green
P B/ Brown Green/White Brown
M Z Black Yellow Black
U Z/ Yellow Yellow/Black Yellow
E U White/Brown Brown White/Brown
R U/ Brown/White Brown/White Brown/White
F V White/Gray Orange White/Gray
S V/ Gray/White Orange/Black Gray/White
G W Red/Orange Violet Red/Orange
H W/ Orange/Red Violet/White Orange/Red
K,L +5VDC Red/Blue Red Red/Blue
Jumper Installed
CONS and TONS
T 0V COMMON Blue/Red Red/White Blue/Red
D THERM Ground Green/Red Black Green/Red
***LONS ONLY
A THERM Signal Red/Green White Red/Green
Z *ENCODER SHIELD N/C N/C *Shield
Motor Power
Cable
Motor Power
Connector PIN #
Power
Connections
Motor Power
Cable Colors
(CONS)
Motor Power
Cable Colors
(TONS/LONS)
4X16SS Cable
Colors (EMC
Cables)
(4 Wire Shielded
Cable)
A R Red Brown Brown
B S Black Black Black
C T Blue Blue Blue
D, E **PE (Ground) **Green/Yellow **Green/Yellow **Green/Yellow
Motor Power
Connections
Shell *Power Shield *Shield *Shield *Shield
