Emerson CORESENSE - Modbus Map - Input Registers; Parameters Readable via Function Code 4

D7.8.4/0112-0415/E 10/17
Figure 9: CoreSense wiring terminals description
Figure 10: Sensor module with current sensor
Power supply crankcase heater Power supply control module
115V or 230V 24V AC
Communication to
CoreSense module
24V AC output
To terminal
plate
Crankcase
heater
Current sensor
Modbus communication port Control module communication
to sensor module
LED Module power
220V or 110V
Contactor
DIP-switch Line
Alarm
Discharge
temperature
sensor
PTC
Oil sensor
