Quick Installation Guide
P/N MHM-97409.4
April 2010
CSI 9420
2
© 2010 CSI. All rights reserved. All marks property of owner.
This installation guide provides basic guidelines for the CSI 9420. It does not provide
instructions for detailed configuration, diagnostics, maintenance, service, troubleshooting,
or installations. Refer to the CSI 9420 reference manual (document number P/N 97408)
for more instruction. The manual and this QIG are also available electronically on
www.mhm.assetweb.com.
Explosions could result in death or serious injury:
Installation of this transmitter in an explosive environment must be in accordance with the
appropriate local, national, and international standards, codes, and practices. Please
review the Product Certifications section for any restrictions associated with a safe
installation.
• Before connecting a 375 Field Communicator in an explosive atmosphere, ensure the
instruments are installed in accordance with intrinsically safe or non-incendive field
wiring practices.
Electrical shock can result in death or serious injury
• Avoid contact with the leads and terminals. High voltage that may be present on leads
can cause electrical shock.
The CSI 9420 and all other wireless devices should be installed only after the 1420
Wireless Gateway has been installed and is functioning properly. Wireless devices should
also be powered up in order of proximity from the 1420 Wireless Gateway, beginning with
the closest. This will result in a simpler and faster network installation.
Shipping considerations for wireless products (Lithium Batteries):
Battery powered units are shipped without the power module installed. Please remove the
power module pack prior to shipping the unit.
Primary lithium batteries are regulated in transportation by the U.S. Department of
Transportation, and are also covered by IATA (International Air Transport Association),
ICAO (International Civil Aviation Organization), and ARD (European Ground
Transportation of Dangerous Goods). It is the responsibility of the shipper to ensure
compliance with these or any other local requirements. Please consult current regulations
and requirements before shipping.
