Emerson CSI 9420 - Configuration with AMS Device Manager

2.3 Configuration with AMS Device Manager
2.3.1 Configure wireless network credentials in AMS Device
Manager
Prerequisites
Before performing operations in AMS Device Manager, first scan the CSI 9420 with a wired
HART modem. Right-click the HART Modem icon in Device Explorer and select Scan All
Devices.
Note
Configuring the wireless network is only applicable using a wired HART modem and cannot be done
using WirelessHART devices.
Procedure
1. Right-click the CSI 9420 device and select Methods > Join Network.
2. Enter the network ID for the wireless network in the Join Device to Network screen
and click Next.
You can obtain the network ID from the Smart Wireless Gateway web server. Click
Setup > Network > Settings.
3. Enter the Join Key in the screens that follow, and click Next.
4. Select the Accept new join key option, and click Next.
5. Click Finish when done.
Configuration
34 MHM-97408, Rev 15
