5.4.5 Last start information
The last start information screen shows details of the most recent successful start:
 start duration (seconds)
 maximum start current drawn (as a percentage of motor full load current)
 calculated rise in motor temperature
Last start 010 s
350 % FLC  Temp 5%
5.4.6 Date and time
The date/time screen shows the current system date and time (24 hour format). For details on setting the date and time, see Set
Date and Time on page 65.
DD MMM YYYY
HH:MM:SS
5.4.7 Performance graph
The performance graph provides a real-time display of operating performance. Use Pr 9F to 9I to select which information to display.
05050.C
000.0 A 0-400%
