Emerson Digistart IS1x0043B series User Manual

Safety
Information
Rating
Data
Mechanical
Installation
Electrical
Installation
Keypad
and
Status
Quick Start
Commissioning
Operation
Programming
Diagnostics
Application
Examples
Technical
Data
Maintenance
Options
82 Digistart IS User Guide
www.controltechniques.com Issue: 4
11. Technical Data
Supply
Mains voltage (L1, L2, L3)
IS4xxxx ......................................................................................................................................... 200 Vac to 440 Vac (± 10%)
IS6xxxx ......................................................................................................................................... 380 Vac to 600 Vac (± 10%)
....................................................................................... or 380 Vac to 690 Vac (± 10%) for grounded star supply system only
Control voltage (CSH, CSL, CSR) .................................................................. 110 to 210 Vac or 220 to 440 Vac (+ 10% / -15%), 1 A
Recommended fuse .......................................................................... 1 A continuous (30 A max, 10 A typical half cycle inrush)
Mains frequency ........................................................................................................................................................ 45 Hz to 66 Hz
Rated insulation voltage to ground ....................................................................................................................................... 600 Vac
Rated impulse withstand voltage ................................................................................................................................................ 4 kV
Form designation ................................................................................ Bypassed or continuous, semiconductor motor starter form 1
Short circuit capability
Coordination with semiconductor fuses ................................................................................................................................... Type 2
Coordination with HRC fuses ................................................................................................................................................... Type 1
IS1x0023B to IS2x0220B .................................................................................................................. prospective current 65 kA
IS3x0255B to IS4x1000B, IS3x0255N ............................................................................................... prospective current 85 kA
IS561200N to IS561600N ............................................................................................................... prospective current 100 kA
Electromagnetic capability (compliant with EU Directive 89/336/EEC)
EMC Emissions .............................................................................................................................................. IEC 60947-4-2 Class B
EMC Immunity ............................................................................................................................................................. IEC 60947-4-2
Inputs
Input rating ............................................................................................................................................. Active 24 Vdc, 8 mA approx
Start (DI1, +24V) ........................................................................................................................................................ Normally open
Stop (DI2, +24V) ...................................................................................................................................................... Normally closed
Reset (DI3, +24V) .................................................................................................................................................... Normally closed
Programmable inputs
Input A (DI4, +24V) ............................................................................................................................................ Normally open
Input B (DI5, +24V) ............................................................................................................................................ Normally open
Motor thermistor (TH1, TH2) .................................................................................................................... Trip >3.6 k, reset <1.6k
PT100 RTD (PT3, PT4, PT5) ........................................ Accuracy 0 to 100 °C  0.5 °C, 100 °C to 150 °C 2°C, -20 to 0 °C  2°C
Outputs
Relay outputs ................................................................................................. 10A @ 250 Vac resistive, 5A @ 250 Vac AC15 pf 0.3
Run relay (COM2, RLO2) ........................................................................................................................................... Normally open
Programmable outputs
Relay A (COM1, RLO1) ..................................................................................................................................... Normally open
Relay B (COM3, RLC3, RLO3) ............................................................................................................................... Changeover
Relay C (COM4, RLC4, RLO4) .............................................................................................................................. Changeover
Analog output (AO1, 0V) ................................................................................................................ 0-20 mA or 4-20 mA (selectable)
Maximum load ................................................................................................................................... 600  (12 Vdc @ 20 mA)
Accuracy ........................................................................................................................................................................... ± 5%
24 Vdc output (+24V, 0V) Maximum load ............................................................................................................................... 200 mA
Accuracy ......................................................................................................................................................................... ± 10%
Environmental
Protection
IS1x0023B to IS1x0105B ................................................................................................................................................... IP20
IS2x0145B to IS4x1000B and IS3x0255N to IS561600N ................................................................................................... IP00
Keypad (when installed with remote mounting kit) ........................................................................................... IP65 & NEMA12
Operating temperature ................................................................................................... -10 ˚C to 60 ˚C, above 40 ˚C with derating*
Storage temperature .............................................................................................................................................. - 25 ˚C to + 60 ˚C
Operating altitude ................................................................................................................. 0 - 1000 m, above 1000 m with derating
Humidity .............................................................................................................................................. 5% to 95% Relative Humidity
Pollution degree ................................................................................................................................................... Pollution Degree 3
Vibration
IS1x0023B to IS4x1000B ................................................................................................................................... IEC 60068-2-6
