Specications
Specications are given for the Type 92B valve on below. Specications for a given valve as it originally comes from
the factory are stamped on the nameplate.
Available Congurations
Pilot-operated globe-style pressure
reducing valve with post guiding and ow-to-close
valve plug action
Body Sizes and End Connection Styles
See Table 1
Body Ratings and Maximum Inlet Pressures
(1)
See Table 3
Maximum Outlet (Casing) Pressure
Cast Iron: 150 psig / 10.3 bar or body rating
limit, whichever is lower
Steel/Stainless steel: 300 psig / 20.7 bar or body
rating limit, whichever is lower
Outlet Pressure Ranges
(1)
See Table 2
Minimum Di󰀨erential Pressure Required for
Full Stroke
(1)
20 psig / 1.4 bar with stainless steel
spring; 10 psig / 0.69 bar with Inconel
®
spring
Pressure Registration
External
Temperature Capabilities
(1)
See Table 3
Downstream Control Line Connections
NPS 1 and 1-1/2 / DN 25 and 40 bodies:
1/4 NPT
NPS 2 / DN 50 body: 3/8 NPT
NPS 3 and 4 / DN 80 and 100 bodies: 1/2 NPT
1. The pressure/temperature limits in this Instruction Manual or any applicable standard limitation should not be exceeded.
Table 1. Body Sizes and End Connection Styles
BODY SIZES END CONNECTION STYLE
NPS DN Cast Iron Body
Steel or
Stainless Steel Body
1 25 NPT
NPT, SWE
(1)
,
CL150 RF,
CL300 RF
and PN 16/25/40 RF
1-1/2 and 2 40 and 50
NPT,
CL125 FF and
CL250 RF
3 and 4 80 and 100
CL125 FF
and CL250 RF
CL150 RF, CL300 RF,
PN 16 RF and PN 25/40 RF
1. Available in steel bodies only.
Table 2. Outlet Pressure Ranges
PILOT TYPE
OUTLET PRESSURE
PART NUMBER COLOR CODE
SPRING WIRE DIAMETER SPRING FREE LENGTH
psig bar In. mm In. mm
Low
Pressure
2 to 6
5 to 15
13 to 25
0.14 to 0.41
0.34 to 1.0
0.90 to 1.7
1E395627022
1D7455T0012
1E395727192
Yellow
Green
Red
0.207
0.234
0.283
5.26
5.94
7.19
2.50
2.62
2.44
63.5
66.5
62.0
High
Pressure
15 to 30
25 to 75
70 to 150
1.0 to 2.1
1.7 to 5.2
4.8 to 10.3
1E395627022
1D7455T0012
1E395727192
Yellow
Green
Red
0.207
0.234
0.283
5.26
5.94
7.19
2.50
2.62
2.44
63.5
66.5
62.0
High
Temperature
15 to 100
80 to 250
1.0 to 6.9
5.5 to 17.2
14B9943X012
14B9942X022
Unpainted
Unpainted
0.282
0.375
7.16
9.53
2.50
2.50
63.5
63.5
Inconel
®
is a trademark owned by Special Metals Corporation.
!
WARNING
The Type 92B safety override system
does not provide positive shuto󰀨 in
dead end service. It is intended for
large distribution systems where steam
leakage will condense before steam
pressure builds up. Downstream piping
and components must be rated for
maximum upstream steam pressure for
dead end service. Failure to do so could
cause personal injury or death.
