Instruction Manual
D103785X012
Field Communicator Menu Trees
June 2017
101
Figure B‐1. Hot Key
Hot Key
1 Instrument Mode
2 Change Instrument Mode
3 Write Protection
4 Change Write Protection
Figure B‐2. Online
Online
1 Overview
2 Configure
3 Service Tools
HART Application
1 Offline
2 Online
3 Utility
4 HART Diagnostics
Figure B‐3. Overview (1)
Device Information
1 Identification
2 Revisions
3 Security
Identification
1 HART Tag
2 HART Long Tag
3 Manufacturer
4 Model
5 Instrument Level
6 Device ID and Serial Numbers
7 Message
8 Description
Overview
1 Device Status
2 Analog Input
3 Setpoint
4 Travel
5 Supply Pressure
6 Pressure A
7 Pressure B
8 Pressure A-B
9 Device Information
Revisions
1 HART Universal Revision
2 Device Revision
3 Hardware Revision
4 Firmware Revision
5 DD Information
Security
1 Write Protection
2 Change Write Protection
1-9 (AD, PD, ODV)
1-9-1 (AD, PD, ODV)
1-9-2 (AD, PD, ODV)
1-8-3 (HC)
2 HART LONG TAG IS AVAILABLE WITH HART 7.
NOTES:
Device ID and Serial Numbers
1 Device ID
2 Valve Serial Number
3 Instrument Serial Number
4 PWB Serial Number
1 SUPPLY PRESSURE IS AVAILABLE FOR INSTRUMENT LEVEL AD, PD, AND ODV.
1-8 (HC)
1-8-1 (HC)
1-8-2 (HC)
1-9-3 (AD, PD, ODV)
1-9-1-5 (AD, PD, ODV, HART 5)
1-8-1-5 (HC, HART 5)
1-8-1-6 (HC, HART 7)
1-9-1-6 (AD, PD, ODV, HART 7)
2
1
Figure B‐4. Configure (2)
Configure
1 Guided Setup
2 Manual Setup
3 Alert Setup
4 Calibration
Figure B‐5. Guided Setup (2-1)
Guided Setup
1 Device Setup
2 Performance Tuner
1 THIS MENU ITEM IS STABILIZE/OPTIMIZE FOR INSTRUMENT LEVEL HC.
1
NOTES:
To Next Page
