Instruction Manual
D103785X012
Parts
June 2017
86
Kit Description Part Number
8* I/P Converter Kit
Standard 38B6041X152
For Extreme Temperature option
(fluorosilicone elastomers) 38B6041X132
9 Adjustment Arm Kit
(includes washer, nut and adjustment arm) 14B5072X132
10* Spare Module Base Assembly Kit
[kit contains module base (key 2); drive screws, qty. 2,
(key 11); shield/label (key 19); hex socket cap screw, qty. 3,
(key 38); self tapping screw, qty. 2 (key 49); pipe plug, qty. 3
(key 61); retaining ring, qty. 3 (key 154); screen (key 236);
and flame arrestors, qty. 3 (key 243)]
GE18654X012
11* Spare Shroud Kit GE29183X012
12 Remote Travel Sensor Assembly
Note
Contact your Emerson sales office
or Local Business Partner for Remote
Travel Sensor Assembly ordering information.
13 Remote Terminal Box Kit GE00418X012
14 Feedback Unit
DVC6015 49B7986X012
DVC6025 long arm 49B7987X012
DVC6025 Short Arm 49B7987X022
DVC6035 49B7988X012
DVC6035 (for GX actuator) 49B7988X022
15 Feedback Unit Termination Strip Kit GE00419X012
16 Pipestand/Wall Mounting Kit GE00420X012
Parts List
Note
Contact your Emerson sales office or Local Business Partner for Part
Ordering information.
Note
Parts with footnote numbers shown are available in parts kits; see
footnote information at the bottom of the page.
Kit Description Part Number
DVC6005 HW2 Base Unit
(see figure 7‐2)
Housing
1 Housing
11 Drive Screw (2 req'd)
20 Shield
52 Vent, plastic
(2)
74 Mounting Bracket
(16)
248 Screw, hex head
(16)
(4 req'd)
249 Screw, hex head
(16)
(4 req'd)
250 Spacer
(16)
(4 req'd)
267 Standoff
(16)
(2 req'd)
271 Screen
Common Parts
16* O-ring
(1)
(3 req'd)
29 Warning label, for use only with LCIE hazardous area
classifications
33 Mach Screw, pan hd, SST
(2)
(3 req'd)
38 Cap Screw, hex socket, SST
(2,10)
(3 req'd)
43* Cover Assembly (includes cover screws)
Standard 38B9580X022
Extreme temperature option
(fluorosilicone elastomers) 38B9580X032
48 Nameplate
49 Screw, self tapping (2 req'd)
(10)
63 Lithium grease (not furnished with the instrument)
64 Pipe thread sealant (not furnished with the instrument)
65 Lubricant, silicone sealant (not furnished with the instrument)
154 Retaining Ring
(2)
(3 req'd)
237 Module Base Seal
(1)
Module Base
2 Module Base
(10)
11 Drive Screw
(10)
(2 req'd)
12 O-ring
(1)
19 Shield Assembly
(10)
61 Pipe Plug, hex socket
(10)
(3 req'd)
236 Screen, for single-acting direct units only
(10)
243 Flame Arrestor Assembly
(10)
(3 req'd)
I/P Converter Assembly
23 Cap Screw, hex socket, SST
(2,11)
(4 req'd)
39* O-ring
(1,8)
41 I/P Converter
(8)
169 Shroud
(8,
11)
210* Boot, nitrile
(1,8)
(2 req'd) (also see figure 6‐4)
231* Seal Screen
(1,6,8)
*Recommended spare
1. Available in the Elastomer Spare Parts Kit
2. Available in the Small Hardware Spare Parts Kit
6. Available in the Seal Screen Kit
8. Available in the I/P Converter Kit
10. Available in the Spare Module Base Assembly Kit
11. Available in the Spare Shroud Kit
16. Available in the Pipestand/Wall Mounting Kit
