Instruction Manual
D103785X012
Field Communicator Menu Trees
June 2017
106
Figure B‐10. Calibration (2-4)
Calibration
1 Travel Calibration
2 Relay Adjust
3 Sensor Calibration
4 PST Calibration
Travel Calibration
1 Auto Calibration
2 Last AutoCal Status
3 Manual Calibration
4 Calibration Record
Sensor Calibration
1 Travel Sensor Adjust
2 Pressures Sensors
3 Analog Input
2-4-1
2-4-3
HART 5
HART 5
HART 7
Travel Calibration
1 Auto Calibration
2 Last AutoCal Status
3 Manual Calibration
4 Calibration Type
5 Calibration Time
6 Calibrator
2-4-1
HART 7
1 PST CALIBRATION IS AVAILABLE FOR INSTRUMENT LEVEL ODV.
1
NOTE:
2
2 ANALOG INPUT IS NOT AVAILABLE WHEN THE DIP SWITCH IS SET TO MULTI-DROP.
Figure B‐11. Service Tools (3)
Service Tools
1 Device Status
2 Alert Record
3 Diagnostics
4 Variables
5 Maintenance
Diagnostics
1 Stroke Valve
2 Partial Stroke Test
3-4
Variables
1 Travel/Pressure
2 Control Mode
3 Analog Input
4 Temperature
5 Travel Counts
6 Characterization
7 Travel History
8 Run Time Extremes
Control Mode
1 Control Mode
2 Change Control Mode
3 Restart Control Mode
3-3
Travel/Pressure
1 Setpoint
2 Travel
3 Drive Signal
4 Supply Pressure
5 Pressure A
6 Pressure B
7 Pressure A-B
8 Travel/Pressure Select
9 Fallback Recovery
Characterization
1 Input Characterization
2 Custom Characterization
Travel History
1 Cycle Counter
2 Travel Accumulator
Run Time Extremes
1 Maximum Recorded Temperature
2 Minimum Recorded Temperature
3 Days Powered Up
4 Number of Power Ups
Maintenance
1 Performance Tuner
2 Stabilize/Optimize
3 Restart Processor
4 Reset Valve Stuck Alert
5 Change to HART 5
3-4-8
3-4-7
3-5
5 THIS MENU ITEM READS CHANGE TO HART 7 WITH HART 5.
3 PERFORMANCE TUNER IS AVAILABLE FOR INSTRUMENT LEVEL AD, PD, AND ODV.
Alert Record
1 View Alert Records
2 Clear Records
3-2
1
2
2
5
3-4-1
3-4-2
3-4-6
1 PARTIAL STROKE TEST IS AVAILALBE FOR INSTRUMENT LEVEL ODV.
2 SUPPLY PRESSURE AND FALLBACK RECOVERY ARE AVAILABLE FOR AD, PD, ODV.
3
4 RESET VALVE STUCK ALERT IS AVAILABLE FOR INSTRUMENT LEVEL OD V.
4
NOTES:
