Emerson Fisher FIELDVUE DVC6000 HW2 User Manual

Instruction Manual
D103785X012
Configuration
June 2017
29
Table 3‐4. Actuator Information for Initial Setup
Actuator
Manufacturer
Actuator
Model
Actuator Size Actuator Style
Starting
Tuning
Set
Feedback
Connection
Travel Sensor Motion
Relay A or C
(1)
Fisher
585C & 585CR
25
50
60
68, 80
100, 130
Piston Dbl with or
w/out Spring. See
actuator instruction
manual and
nameplate.
E
I
J
L
M
SStem-Standard
for travels up to
4 inches.
SStem-Roller for
longer travels
Depends upon pneumatic connections.
See description for Travel Sensor Motion
657
30
34, 40
45, 50
46, 60, 70, 76, &
80‐100
Spring & Diaphragm
H
K
L
M
SStem-Standard Clockwise
667
30
34, 40
45, 50
46, 60, 70, 76, &
80‐100
Spring & Diaphragm
H
K
L
M
SStem-Standard Counterclockwise
1051 & 1052
20, 30
33
40
60, 70
Spring & Diaphragm
H
I
K
M
Rotary Clockwise
1061
30
40
60
68, 80, 100, 130
Piston Dbl w/o Spring
J
K
L
M
Rotary
Depends upon pneumatic connections.
See description for Travel Sensor Motion
1066SR
20
27, 75
Piston Sgl w/Spring
G
L
Rotary
Mounting Style Travel Sensor Motion
A Clockwise
B Counterclockwise
C Clockwise
D Counterclockwise
2052
1
2
3
Spring & Diaphragm
H
J
M
Rotary Clockwise
3024C
30, 30E
34, 34E, 40, 40E
45, 45E
Spring & Diaphragm
E
H
K
SStem-Standard
For P
o
operating mode (air opens):
Counterclockwise
For P
s
operating mode (air closes):
Clockwise
GX
225
Spring & Diaphragm
X
(1)
SStem-Standard
Air to Open Air to Close
750 K
Counterclockwise Clockwise
1200 M
Baumann
Air to Extend
16
32
54
Spring & Diaphragm
C
E
H
SStem-Standard
Clockwise
Air to Retract Counterclockwise
Rotary
10
25
54
E
H
J
Rotary Specify
1. X = Expert Tuning. Proportional Gain = 4.2; Velocity Gain = 3.0; Minor Loop Feedback Gain = 18.0
2. Values shown are for Relay A and C. Reverse for Relay B.
D Proportional Gain—The proportional gain for the travel control tuning set. Changing this parameter will also change
the tuning set to Expert.
D Velocity Gain—The velocity gain for the travel control tuning set. Changing this parameter will also change the
tuning set to Expert.
D MLFB Gain—The minor loop feedback gain for the travel control tuning set. Changing this parameter will also
change the tuning set to Expert.
