DVC6000f Series
March 2006
5-44
Table 5-13. Transducer Block Parameter Definitions (Continued)
Label
PARAMETER_NAME
Description
Protect
Category
Initial ValueRangeMode
RO /
RW
Index
Number
Basic Setup
BASIC_SETUP
42
Actuator Style
ACTUATOR_STYLE
42.1 RW
MAN
OOS
1=Spring & Diaphragm
2=Piston-Dbl w/o Spring
3=Piston-Dbl w/Spring
4=Piston Sgl w/Spring
1=Spring &
Diaphragm
SETUP Data Type: Enum
Zero Pwr Cond
ZERO_PWR_COND
42.2 RW
MAN
OOS
1=Valve Closed
2=Valve Open
1=Valve Closed SETUP
Data Type:
Enum Identifies whether the valve
is open or closed when instrument
power is lost.
Tvl Sen Motion
TRAVEL_SEN_MOTION
42.3 RW
MAN
OOS
1=Counter Clockwise
2=Clockwise
1=Counter
Clockwise
SETUP Data Type: Enum
Feedback Conn
FEEDBACK_CONN
42.4 RW
MAN
OOS
1=Rotary All
2=Sstem Roller
3=Sstem Standard
3=Sstem
Standard
SETUP Data Type: Enum
Relay Type
RELAY_TYPE
42.5 RW
MAN
OOS
1=Type A
2=Type B
1=Type A SETUP Data Type: Enum
Max Supp Press
MAX_SUPP_PRESS
42.6 RW
MAN
OOS
> 0, < = 150 35 psig SETUP Data Type: Float
Press Range Hi
PRESS_RANGE_HI
42.7 RW
MAN
OOS
> 0, < = 150 15.0 psig SETUP
Data Type: Float
Defines pressure corresponding to
max pressure in pressure control
mode.
Press Range Lo
PRESS_RANGE_LO
42.8 RW
MAN
OOS
> = 0, < = 150 3.0 psig SETUP
Data Type: Float
Defines pressure corresponding to
minimum pressure in pressure
control mode.
Tvl Cal Trigger
TVL_CAL_TRIGGER
42.9 RW
MAN
OOS
1 = Aux Term ignored 1 SETUP Not available in the DVC6000f
Tvl Tuning Set
TVL_TUNING_SET
42.10 RW
MAN
OOS
1=B, 2= C, ...12=M
23=X
2=C SETUP
Data Type: Enum
Letter (B through M or X)
Press Tuning Set
PRESS_TUNING_SET
42.11 RW
MAN
OOS
1=B, 2=C, ...12= M
23=X
2=C SETUP
Data Type: Enum
Letter (B through M or X)
TRAVEL_CAL
43
Tvl Count
TVL_COUNT
43.1 RO N/A
Data Type: Uint16
Raw feedback from Travel Sensor
Tvl Hi Cal
TVL_HI_CAL
43.2 RW
MAN
OOS
<TVL_FAC_HI
>TVL_LO_CAL
CAL
Data Type: Uint16
Max drive calibration point
Tvl Lo Cal
TVL_LO_CAL
43.3 RW
MAN
OOS
>TVL_FAC_LO
<TVL_HI_CAL
CAL
Data Type: Uint16
Min drive calibration point
Tvl Crossover
TVL_CROSSOVER
43.4 RW
MAN
OOS
>0% < = 100% 50% CAL Data Type: Float
Tvl Fac Hi
TVL_FAC_HI
43.5 RO N/A Set by Factory N/A
Data Type: Uint16
Maximum value of travel sensor
counts. Set at factory.
Tvl Fac Lo
TVL_FAC_LO
43.6 RO N/A Set by Factory N/A
Data Type: Uint16
Minimum value of travel sensor
counts. Set at factory.
Tvl IP Bias
TVL_IP_BIAS
43.7 RW
MAN
OOS
0% − 100% 70% CAL Data Type: Float
Tvl MLFB Bias
TVL_MLFB_BIAS
43.8 RW
MAN
OOS
0 − 100% 50% CAL Data Type: Float
−Continued−
