375 Field Communicator Resource Block Menu Structure
PARAMETER LABEL PARAMETER NAME MENU STRUCTURE
Acknowledge Option ACK_OPTION RB > Setup > Alarm Handling > Acknowledge Option
Alarm Summary: Disabled ALARM_SUM.DISABLED RB > Setup > Alarm Handling > Alarm Summary Disabled
Alert Key ALERT_KEY RB > Setup > Alarm Handling > Alert Key
Block Alarm:
Unacknowledged
BLOCK_ALM.UNACKNOWLEDGED
RB > Setup > Alarm Handling > Block Alarm:
Unacknowledged
Block Error BLOCK_ERR RB > Display > Resource Status > Block Error
Confirm Time CONFIRM_TIME RB > Setup > Alarm Handling > Confirm Time
Device ID DEVICE_ID RB > Display > Instrument > Device ID
Device Revision DEV_REV RB > Display > Instrument > Device Revision
Device State RS_STATE RB > Display > Resource Status > Device State
Device Type DEV_TYPE RB > Display > Instrument > Device Type
DD Revision DD_REV RB > Display > Instrument > DD Revision
Diag Options DIAG_OPTIONS RB > Display > Options > Diag Options
Electronics Serial Number ELECTRONICS_SN RB > Display > Instrument > Electronics Serial Number
Factory Serial Number FACTORY_SN RB > Display > Instrument > Factory Serial Number
Fault State FAULT_STATE RB > Display > Resource Status > Fault State
Features FEATURES RB > Display > Instrument > Features
Feature Selection FEATURE_SEL RB > Setup > Options > Feature Selection
Field Serial Number FIELD_SN RB > Setup > Instrument > Field Serial Number
Function Block Options FB_OPTIONS RB > Display > Options > Function Block Options
Hardware Revision HARDWARE_REV RB > Display > Instrument > Hardware Revision
ITK Version ITK_VER RB > Display > Instrument > ITK Version
Manufacturer ID MANUFAC_ID RB > Display > Instrument > Manufacturer ID
Max Alerts Allow LIM_NOTIFY RB > Setup > Alarm Handling > Max Alerts Allow
Misc Options MISC_OPTIONS RB > Display > Options > Misc Options
RCas Timeout SHED_RCAS RB > Setup> Comm Time Out > RCas Timeout
ROut Timeout SHED_ROUT RB > Setup > Comm Time Out > ROut Timeout
Software Rev All SOFTWARE_REVISION.SOFTWARE_REV_ALL RB > Display > Instrument > Software Rev All
Stby Software Rev All STBY_SOFTWARE_REV.STBY_SOFTWARE_REV_ALL RB > Display > Instrument > Stby Software Rev All
Strategy STRATEGY RB > Setup > Instrument > Strategy
Tag Description TAG_DESC RB > Setup > Instrument > Tag Description
Write Alarm: Alarm State WRITE_ALM.ALARM_STATE RB > Display > Resource Status > Write Alarm: Alarm State
Write Lock WRITE_LOCK RB > Setup > WriteLock> Write Lock
Write Priority WRITE_PRI RB > Setup > WriteLock> Write Priority
