View Lists
View lists allow the values of a set of parameters to be
accessed at the same time. Views 1 and 2 contain
operating parameters and are defined by the Fieldbus
Foundation. View 3 contains dynamic parameters and
View 4 contains static parameters with configuration
and maintenance information. Views 3 and 4 are
defined by the manufacturer.
Table 5-72. DO Function Block, View 1
Index
Number
Parameter
1 ST_REV
5.1 MODE_BLK.TARGET_MODE
5.2 MODE_BLK.ACTUAL_MODE
5.3 MODE_BLK.PERMITTED_MODE
5.4 MODE_BLK.NORMAL_MODE
6 BLOCK_ERR
7 PV_D
8 SP_D
9 OUT_D
16 READBACK_D
17 CAS_IN_D
Table 5-73. DO Function Block, View 2
Index
Number
Parameter
1 ST_REV
11 PV_STATE
12 XD_STATE
13.1 GRANT_DENY.GRANT
13.2 GRANT_DENY.DENY
Table 5-74. DO Function Block, View 3
Index
Number
Parameter
1 ST_REV
5.1 MODE_BLK.TARGET_MODE
5.2 MODE_BLK.ACTUAL_MODE
5.3 MODE_BLK.PERMITTED_MODE
5.4 MODE_BLK.NORMAL_MODE
6 BLOCK_ERR
7 PV_D
8 SP_D
9 OUT_D
16 READBACK_D
17 CAS_IN
21 BKCAL_OUT_D
22 RCAS_IN_D
24 RCAS_OUT_D
Table 5-75. DO Function Block, View 4
Index
Number
Parameter
1 ST_REV
3 STRATEGY
4 ALERT_KEY
14 IO_OPTS
15 STATUS_OPTS
18 CHANNEL
19 FSTATE_TIME
20 FSTATE_VAL_D
24 SHED_OPT
27 SP_RATE_UP
28 SP_RATE_DN
