Instruction Manual Supplement
D104205X012
DVC6200 Digital Valve Controllers
November 2020
5
Figure 1. ATEX Loop Schematics—FIELDVUE DVC6200 HW2 and DVC6200 SIS
Ui = 30 VDC
Ii = 130 mA
Pi = 1.0 W
Ci = 15 nF
Li = 0.15 mH
LOOP TERMINALS
AUX TERMINALS
LOOP TERMINALS
Ex ia IIC
LOOP TERMINALS
Ex ia IIB
Ui = 30 VDC
Ii = 101 mA
Pi = 757 mW
Ci = 15 nF
Li = 0.30 mH
Ui = 27.1 VDC
Ii = 130 mA
Pi = 880 mW
Ci = 15 nF
Li = 0.30 mH
Ui = 30 VDC
Ii = 130 mA
Pi = 1.0 W
Ci = 15 nF
Li = 0.30 mH
Uo = 30 VDC
Io = 101 mA
Po = 757 mW
Co = 52.4 nF
Lo = 5.84 mH
Not Used or
Not Provided
AUX TERMINALS
Uo = 27.1 VDC
Io = 130 mA
Po = 880 mW
Co = 75 nF
Lo = 2.73 mH
AUX TERMINALS
Uo = 30 VDC
Io = 130 mA
Po = 1.0 W
Co = 546 nF
Lo = 16.93 mH
HW2 - WITH OR WITHOUT I/O PACKAGE
DVC6200, DVC6200S
AUX TERMINALS
LOOP TERMINALS
Ex ia IIC
Ui = 28 VDC
Ii = 100 mA
Pi = 1.0 W
Ci = 15 nF
Li = 0.20 mH
OUTPUT TERMINALS
Ex ia IIC or Ex ia IIB
ATEX APPROVED
BARRIER
ATEX APPROVED
BARRIER
NOTE 5 1
NOTE 1, 3, 4 1
NOTE 1, 3, 4 1
POWER MAY BE APPLIED TO EITHER THE LOOP
TERMINALS OR OUTPUT TERMINALS OR TO
BOTH SETS OF TERMINALS AT THE SAME TIME
UNITS WITHOUT I/O PACKAGE WILL NOT HAVE
“OUTPUT TERMINALS” OR “AUX TERMINALS”
AVAILABLE FOR CONNECTION
ZONE 0, Ex ia IIC or Ex ia IIB
DVC6200
DVC6200S
ZONE 20, Ex ia IIIC
MAX
SURFACE
TEMP
T91_C
T85_C
T AMB
≤ 80_C
≤ 74_C
T AMB
≤ 80_C
≤ 74_C
T CODE
T5
T6
TYPE
WITH I/O
PACKAGE
WITH I/O
PACKAGE
WITHOUT I/O
PACKAGE
WITHOUT I/O
PACKAGE
T AMB
≤ 80_C
≤ 61_C
T CODE
T5
T6
MAX
SURFACE
TEMP
T104_C
T85_C
T AMB
≤ 80_C
≤ 61_C
ZONE 0, Ex ia IIC
ZONE 0, Ex ia IIB
ZONE 20, Ex ia IIIC
HAZARDOUS LOCATION NON‐HAZARDOUS LOCATION
1 SEE NOTES IN FIGURE 6
GE60771 Sheet 11, Rev. D
*Li = 0.15 mH WHEN THE AUX
TERMINALS ARE NOT USED OR IF
THEY ARE NOT PROVIDED
*
To Next Page
