Instruction Manual
D104239X012
Multiport Flow Selector
January 2019
47
WARNING
Extreme caution must be used when writing port calibration values to registers 211 through 218 (40212 thru 40219). Only
values read from these registers shall be written to them. The purpose of these registers is to allow the network host to
store the port calibration values and then write them back to the actuator in case of replacement of the CPU module.
Foundation Fieldbus (FF)
The MPA uses a CAM18 to convert between Modbus and Foundation Fieldbus. Refer to Bettis M2CP CAM18 & TEC2000
CAM218 Installation, Operation and Instruction Manual for installation and setup of the FF link. Relations between the
Modbus and FF maps are identified as follows.
Foundation Fieldbus
Modbus Discrete Input Map Actuator Readback (Channel 2)
Note: Channel 2 has only 1 value
Input DI PV / Out_D
16 At port within 1 degree 1
17 At port within 2 degrees 2
18 Flow selector moving 4
19 Wrong direction alarm 5
Modbus Discrete Input Map Actuator Status (Channel 5)
Note: Channel 5 has only 1 discrete value and depends upon Selector Switch position.
DI PV / Out_D
Input AUTO OFF LOCAL
20 SS Local/Manual 3
Selector Switch Off 2
21 SS Remote/Auto 0
22 Over torque alarm 56 58 59
23 Stop between ports alarm 52 54 55
24 Flow selector stall alarm 9 11 12
25 Power monitor alarm 12 14 15
26 Motor thermal overload alarm 20 22 23
27 Phase monitor alarm 76 78 79
28 Local ESD alarm 40 42 43
29 Actuator fail alarm 44 46 47
Coil Map (Discrete Network Control) Actuator Command (Channel 1)
Coil DO SP / Out_D
10 Go to Next Port 1
Coil Map (Discrete Network Control) ESD Command (Channel 10)
Coil DO SP / Out_D
11 Host ESD Command 1
Monitor and Control Registers Analog input / Output Channels
Register
11 Port Position Setpoint (0-7 or 1-8) Setpoint AO (Channel 3) SP / OUT
14 Port position (0-4095) Position AI (Channel 4) SP / OUT
15 Torque (0-99%) Torque AI (Channel 18) SP / OUT
